Weld-On Bullet Hinge .61 x 3.15" - FBP080GF

Regular price
$3.46
Sale price
$3.46

Part # FBP080GF
Weld-On Bullet Hinge
Overall Length: 3.75" long
  • Finish: Plain
  • Hinge Length: 3.15 "
  • Material: Carbon Steel
  • Mounting Type: Weld-on
  • Thickness: 0.61 "
  • Pin Diameter2: 0.32 "
  • Overall Diameter: 0.51 "
  • Greasable: Yes
  • Pin Length A: 1.28 "
  • Pin Length B: 0.08 "
  • Pin Material: Brass
  • Bushing Material: Brass
  • --- !>
